High frequency relays

Switching frequencies ≤26.5GHz; wide range of types including THT, SMD & SMA connectors.
High frequency relays product hero

Tailored to our customers' needs

PCB HF relays are available as SMD and through-hole types for frequencies up to 8GHz. Coaxial switches with SMA connectivity handle frequencies up to 26GHz line-up includes SPDT, DPDT and SP6T types.

Latest RF switching technology for high frequency applications

RN relay
High frequency relays

RN series

This miniature SMD design is designed for high power switching with excellent high frequency characteristics ≤8GHz.
RS relay
High frequency relays

RS relay: 3GHz

Excellent high frequency characteristics ≤3GHz and a broad range including E and Y layouts and reversed contact type
RD coaxial switch
COAXIAL SWITCH

RD series: ≤26GHz with SMA connectors

SPDT, DPDT & SP6T types.
RJ Relay
High frequency relays

RJ Relay

Excellent high frequency characteristics in a small size.
RV relay
High frequency relays

RV relay

Ultra small high frequency relay with PIN and SMA connection.
RA relay
High frequency relays

RA relay

1 GHz capable, 3 W carrying power (at 1 GHz), 50Ω impedance and 2 Form C relays.
RE relay
High frequency relays

RE relay

2.6 GHz capable, 10 W carrying power (at 2.6 GHz), 50Ω/75Ω impedance,1 Form C relays.
Product Finder

Use the Product Finder to find the best product for you

product finder Panasonic Industry
Find the optimal product for your project by selecting attributes and filter criteria
Go to Product Finder

Downloads

Name File type Size Date Language
PDF Catalog microwave devices Catalog 393KB 27.07.2017 English
PDF Relay technical information Relay 3MB English
PDF Cautions for use - application in circuits Relay 96KB English
PDF Cautions for use - relay terminology Relay 53KB English
PDF Cautions for use - general application guideline Relay 367KB English
PDF Cautions for use - soldering & cleaning Relay 59KB English
PDF Cautions for use - SMT soldering guideline Relay 65KB English
PDF Cautions for use - reliability Relay 41KB English
PDF Short Form Relay Catalog, Shortform 5MB 04.03.2021 English
