ESD suppressor

ESD suppressors have excellent electrostatic-noise suppression and ESD withstanding characteristics and ultra low capacitance.
circuit-protection ESD suppressor hero

Line-up

  ESD suppressor
(General purpose)
ESD suppressor
(15kV Type)
ESD suppressor array ESD suppressor
High withstanding type
Part no. EZAEG2A50AX EZAEG3A50AV EZAEG1N50AC EZAEG2N50AX EZAEGCA50AV EZAEG3W11AV
Size mm (inch) 1005 (0402) 1608 (0603) 0603 (0201) 1005 (0402) 2012 (0805) 1608 (0603)
Off-state
Capacitance (pF)
0.10 max.
(0.05 typical)
0.20 max.
(0.10 typical)
0.08 max.
(0.04 typical)
0.10max.
(0.05 typical)
0.30 max.
(0.25 typical)
0.10 +0.10/-0.08
Peak voltage 500V max.
(350V typical)
1000V max.
(700V typical)
Clamp voltage 100V max. -
ESD withstanding Contact 8kV Contact and Air 15kV Contact 8kV ISO10605
Air 25kV
Rated voltage (DC) 30 V 15 V 50 V
Datasheet Download Download Download Download

Features

ESD suppressor...

...is an ESD protection device using gap discharge.

...protects electric devices from ESD - utilizing the ability to decrease its resistance value rapidly when high voltage is applied to the ESD Suppressor.

...contributes to ensure the signal quality of high-speed serial data lines and high frequency circuits in normal useage (high voltage not applied).
