Power series - Slim type with high capacity

PhotoMOS® 1 Form A and 1 Form B relays featuring High Capacity up to 10A in a Slim Single in Line Package. This series can switch a wide range of current and voltages to control various types of loads for high density mounting. Other features include a low on-resistance down to 0.015Ω, high sensitivity LED with a 1mA operating current. Unlike Triacs, photocouplers or solid-state Relays, PhotoMOS® Relays can be used to control low-level analog signals of less than several hundred millivolts without distortion.

Key features

  • High capacity, High sensitivity, and Low on-resistance
  • Controls low-level analog signals
  • Slim SIL4-pin package
  • High I/O isolation voltage of 2,500 V
  • Both AC/DC dual types and DC-only types available
  • Eliminates the need for a counter electromotive protection diode in the drive circuit on the input side. Eliminates the need for a power supply to drive the power MOSFET.
  • No restriction on mounting direction Low thermoelectromotive force
  • Neither noise nor arc at contact
  • Sockets are also available.

Industry & Infrastructure

Industry & Infrastructure

• Traffic signals
Power supply unit
Industry & Eco Market

Industry & Eco Market

• Industrial machines
• Photovoltaic power generation system
• Battery system
Measurement Market

Measurement Market

• Measuring instruments
