DW series relay: small footprint; maximum possible switching capacity
Reflow-compatible 16A relay
DW series devices are ≤16A latching relays that features three basic types. The standard type with a height of 18.8mm provides pin-in-paste reflow compability and a switching capability of 8A 250VAC. For applications that require high inrush current up to 100A and switching capability of 16A 277VAC, the DW-HL version is the best choice. In addition it offers a lower height of only 15.8mm. Both versions are available as IEC60335-1*-compliant types for household and similar electrical appliances.
Key Features
- Small area on PCB:10 mm width
- Sensitive coil;low power consumption
- TV8 rating
- Reflow-compatible
- IEC 60335-1-compliant
- Low profile type (15.8mm height)
- UL/C-UL, VDE certified
Smart meters
- Digital meters
IoT
- Smart plugs
- Smart switches
- Light-shutter controls
Home appliances
- Washing machines
- Dishwashers
- Dryers
