Micro chip fuses
Line-up
The fuses come in three different sizes and correspond to a rated current ranging from 0.25 A to 5.0 A.
| Series | ERBRD | ERBRE | ERBRG | |
|---|---|---|---|---|
| Datasheet | Download | Download | Download | |
| Size | 1005 (0402) (1.0x0.5x0.39 mm) |
1608 (0603) (1.6x0.8x0.54 mm) |
3216 (1206) (3.2x1.6x0.65 mm) |
|
| Rated voltage | 32 V.DC | 32 V.DC | 32 V.DC (2.5A or more) 63 V.DC (2.0A or less) |
|
| Interrupting rating | 35 A | 50 A | 50 A | |
| Safety standards | UL248-14 , c-UL C22.2 No.248-14 | |||
| Rated current | 0.25 A | ERBRD0R25X | - | - |
| 0.315 A | ERBRD0R31X | - | - | |
| 0.375 A | ERBRD0R37X | - | - | |
| 0.5 A | ERBRD0R50X | ERBRE0R50V | ERBRG0R50V | |
| 0.63 A | ERBRD0R63X | - | - | |
| 0.75 A | ERBRD0R75X | ERBRE0R75V | ERBRG0R75V | |
| 1.0 A | ERBRD1R00X | ERBRE1R00V | ERBRG1R00V | |
| 1.25 A | ERBRD1R25X | ERBRE1R25V | ERBRG1R25V | |
| 1.4 A | - | ERBRE1R40V | - | |
| 1.5 A | ERBRD1R50X | ERBRE1R50V | ERBRG1R50V | |
| 2.0 A | ERBRD2R00X | ERBRE2R00V | ERBRG2R00V | |
| 2.5 A | ERBRD2R50X | ERBRE2R50V | ERBRG2R50V | |
| 3.0 A | ERBRD3R00X | ERBRE3R00V | ERBRG3R00V | |
| 3.15 A | - | ERBRE3R15V | - | |
| 4.0 A | ERBRD4R00X | ERBRE4R00V | ERBRG4R00V | |
| 5.0 A | ERBRD5R00X | ERBRE5R00V | - | |
