Electromechanical and semiconductor relays panasonic industry

PA-N series: 5A slim device; reinforced insulation to IEC61010

Optimized for industrial automation applications such as controls and I/O modules. Conforms to the ANSI/ISA 12.12.01 standard for hazardous locations.
PA-N power relay shadow Panasonic Industry

World’s smallest 5A ATEX relay

Wherever space is precious nowadays – and that is the case in a vast number of contemporary applications, PA-N relay is a perfect choice. Combining the narrow width of 5mm with the low nominal operating power of 110mW comfortably enables high density mounting. The ATEX certification allows the usage in potential explosive environments with currents up to 5A. Additionally, PA-N series ability to operate in a temperature range up to 110°C – next to the superior insulation resistance – makes the IEC61010 compliant relay a perfect option for demanding product designs.

Key features

  • Small size 20 x 12,5 x 5 mm
  • 5A 250 VAC, 5A 30 VDC
  • High reliable bifurcated contacts
  • Minimal switching load 1mA 5VDC
  • Nominal operating power of 110mW
  • Coil voltage 3VDC up to 24VDC
  • Ambient temperature up to 110°C
  • Sealed construction RTIII
  • ATEX conformity
  • Reinforced insulation according to IEC61010-2
Product Finder

Use the Product Finder to find the best product for you

product finder Panasonic Industry
Find the optimal product for your project by selecting attributes and filter criteria
Go to Product Finder

Industrial Automation

Industrial automation Panasonic Industry
  • Output relay for PLC
  • Temperature controllers
  • Timers

Building Automation

Building Automation application Panasonic Industry
  • Smart plugs / smart switch
  • Heating control
  • IoT applications


Measuring application Panasonic Industry
  • Test equipment
  • I/O boards
  • Output relay
