PhotoMOS® HF series, High functioned - with low ON resistance

Photo-coupled semiconductor relays with optimized, low ON resistance for low power dissipation and high power switching.

Higher power for a better environment

Application environment sustainability Panasonic Industry

The latest innovation of PhotoMOS® relay technology is nothing less than a milestone in regards of power output- For example AQV209G HF series 1 Form A high-capacity type can switch up to 1,200V 0.75A, both AC and DC loads.

Panasonic Industry extends successful HF high-capacity series with a new 600V type, AQY206GV in the compact SSOP package which offers an outstanding high voltage capability.  

Key features

  • Up to 1,200V load voltage

  • Up to 0.75A load current

  • AC / DC dual use

  • 1FormA type

  • Different Packages

  • Noiseless switching

  • Endless lifetime

  • Galvanic isolation between input and output circuit

Applications

  • Industrial equipment

  • I/O modules

  • Controls

  • Measuring equipment

  • Testing equipment

  • Replacement of reed relays

  • Replacement mercury containing relays

Check further PhotoMOS® power relays

PD series, Power DIP

PD series, Power DIP

- Flat package - DIP4-pin type - High capacity up to 2A load current
Power series in slim package

Power series in slim package

Up to 10A switching, DC only and AC/DC dual use available for machine tools, robots,iIndustrial equipment and facilities.
HE series, High functioned and Economical – low on resistance

HE series, High functioned and Economical – low on resistance

Medium power capability for use in industrial applications; wide range of 1 Form A, 1 Form B, 2 Form A and 1 Form A 1 Form B types.
