SFM super-low profile safety relay

With a height of only 7.8mm, the SFM is the world’s lowest profile relay with forcibly-guided contacts according to EN 61810-3. Reflow soldering capability enables a new era of production efficiency.
SFM relay hero

Miniaturization for all safety applications

With a height of only 7.8mm, SFM is the world’s lowest profile relay with forcibly-guided contacts according to EN 61810-3. In addition, the 1a1b relay is available as a reflow (THR) version, contributing to a simplified and cost-efficient production process. SFM series can be used to miniaturize all kinds of safety applications, from railway signaling boards with a focus on low level loads to high power safety relays or safety controls.

Key Features

  • 1NO/1NC relay with forcibly-guided contacts according to EN 61810-3
  • Extremely low height of 7.8mm
  • Rating 6A (NO), 4A (NC) @ 250VAC, 30VDC
  • 100mW coil holding power
  • High shock resistance >20g
  • THT & THR types available
  • Reinforced insulation ≥ 5.5mm (V=230V over-voltage category III, 6kV) on NO side
  • Coil voltage from 3 to 24V
  • Ambient temperature -40 to +85°C
Product Finder

Use the Product Finder to find the best product for you

product finder Panasonic Industry
Find the optimal product for your project by selecting attributes and filter criteria
Go to Product Finder

Industrial automation

Application industrial automation Panasonic Industry
  • Safety relay modules
  • Safety controllers
  • Safe motion control

Building automation

SFM safety relay buiding automation Panasonic Industry
  • Elevator control
  • Escalator control
  • Access control


Application transportation train Panasonic Industry
  • Railway signaling
  • Train door control
  • Station access control
