Electromechanical and semiconductor relays panasonic industry

Automotive relays

Offering the best relays with globally-proven high reliability.

World's leading company for automotive relays

Our large automotive relay product portfolio is perfectly suited to meet the ever-increasing demands for versatility and innovation in automotive electronics for almost all applications.

The correct switching solution for every automotive application

EV relay (DC contactors)
Automotive relays

EV relay (DC contactors)

Relays for electro-mobility. High carrying current; high short circuit tolerance and strong cut-off capability ≤300A.
TB relay: 30A
Automotive relays

TB relay: 30A

High carrying-current 1 Form A type miniature PCB relay.
TL relay: 2 Form A
Automotive relays

TL relay: 2 Form A

40A high load device for smart junction boxes; double make contact.
CJ relay: 20A
Automotive relays

CJ relay: 20A

Compact, slim twin and single devices; PiP types available.
CN-H relay: 30A
Automotive relays

CN-H relay: 30A

Sealed, high heat-resistant relay for smart junction boxes
CN-M relay: 30A
Automotive relays

CN-M relay: 30A

Sealed 1 Form A / 1 Form C types for smart Junction boxes; SMD versions available
CP relay: compact
Automotive relays

CP relay: compact

Low profile 1 Form A / 1 Form C relays ≤20A
CP relay: power type
Automotive relays

CP relay: power type

Miniature, low profile 1 Form A / 1 Form C high carrying current relay
TM relay: 35A low profile relay
Automotive relays

TM relay: 35A low profile relay

High capacity, 1 Form A / 1 Form C relay for smart junction boxes
CQ relay: 20A
Automotive relays

CQ relay: 20A

1 Form C relay; quiet operation; wiper load types available
CT relay: 20A
Automotive relays

CT relay: 20A

Small and slim twin / 1 Form C type automotive relay.
CW relay: high power
Automotive relays

CW relay: high power

≤120A carrying current relay for failsafe circuits in high output motors (EPS)
EV series: safety switch
Automotive relays

EV series: safety switch

High voltage DC cut-off switches use capsule contact mechanism
TA relay: 20A switching capability
Automotive relays

TA relay: 20A switching capability

1 Form C sealed relay; quiet operation
TB series: 20A
Automotive relays

TB series: 20A

- Miniature PCB-mount - Twin /1 Form C - Sealed and PiP types available
TC relay: ≤30A
Automotive relays

TC relay: ≤30A

High load relay for smart junction boxes miniature; sealed and PiP types available
TE relay: 20A
Automotive relays

TE relay: 20A

- Miniature PCB-mount relay - Twin / 1 Form C - Sealed and PiP types available
TG relay: 30A sealed power relay
Automotive relays

TG relay: 30A sealed power relay

High load relay for smart junction boxes; low power consumption
TH relay: low profile, 20A
Automotive relays

TH relay: low profile, 20A

- Miniature, low profile (8.8mm) PCB-mount - Twin, 1 Form C - Surface-mount
TJ relay
Automotive relays

TJ relay

30A 1 Form C sealed relay for smart junction boxes
TM relay: 35A
Automotive relays

TM relay: 35A

High capacity relay for smart junction boxes; 1 Form A / 1 Form C, sealed
TT 60A automotive relay
Automotive relays

TT 60A automotive relay

Compact and high capacity double make contact 2 Form A (1 Form U), Pin in Paste compliant type available.
CA relay: plug-in type
Automotive relays

CA relay: plug-in type

- Small size, light weight - JIS-compliant terminal arrangement - Rubber bracket A, screw mounting or direct coupling types
CB relay: ≤70A
Automotive relays

CB relay: ≤70A

Mini-ISO automotive relay; 1 Form A and 1 Form C
CM relay
Automotive relays

CM relay

Micro-ISO automotive relay; 1 Form A and 1 Form C
CV-N relay: 35A micro-ISO
Automotive relays

CV-N relay: 35A micro-ISO

Low profile, Micro-ISO automotive relay; 1 Form A
CN-L relay: 150A latching type
Automotive relays

CN-L relay: 150A latching type

150A (max.) continuous carrying current latching relay; 1 Form A, sealed
EC-N relay
Automotive relays

EC-N relay

Small, high capacity, high voltage DC plug-in relay; 1 Form A, sealed

Find the optimal product for your project by selecting attributes and filter criteria
Go to Product Finder

Downloads

Name File type Size Date Language
PDF Automotive Relay Terminology Data sheet, Technical information 64 KB 26.03.2024 English
PDF Cautions for use - Automotive user guide Data sheet, Technical information 415 KB 26.03.2024 English
PDF Cautions for use - Configuration & Construction vehicle Data sheet, Technical information 52 KB 20.08.2020 English
PDF Cautions for use - Relay Terminology Data sheet, Technical information 54 KB 28.02.2014 English
PDF Relays Short Form 2024 Catalog, Shortform 5 MB 19.02.2024 English
PDF Taiko - Panasonic part no. reassignment list Data sheet, Technical information 236 KB 20.08.2020 English
