ERZA80JK561C
Varistor Type: J
Product specifications for this product
| Item | Product specifications |
|---|---|
| Voltage | 560 V |
| Clamping voltage (max.) | 925 V |
| Voltage range (max.) | 615 V |
| Voltage range (min.) | 505 V |
| Height | 140 mm |
| Weight (Typ.) | 2500 g |
| Packaging | - |
| Width | 110 mm |
| Series | C |
| Thickness [SMD: Length] | 200 mm |
| Element size | - |
| Lead type | - |
| Max. allowable voltage ACrms | 250 V |
| Max. allowable voltage DC | 350 V |
| Max. energy (2ms) | 20000 J |
| Max. peak current (8/20 µs) | 320000 A |
| Lead Spacing W | 40 mm |
