EX-19EA-PN
Product specifications for this product
| Item | Product specifications |
|---|---|
| Sensor type | Miniature |
| Sub category | Thru-beam |
| Sensing range | 1 m |
| Output | PNP |
| Output operation | Light-ON |
| Connection method | Cable |
| Response time | 0.5 ms |
| Emitting element | LED red |
| Power supply | 12 to 24V DC |
| Protection | IP 67 |
| Temperature range | -25 to +55°C |
| Material | Plastic |
| Sensing height | - |
| Sensor category | Photoelectric |
