Board-to-FPC connectors
Reliable Board-to-FPC Connectivity for Demanding Designs
Panasonic Industry’s CF1, CF2 and CF3 Board-to-FPC connectors provide reliable direct connections between flexible printed circuits (FPCs) and PC boards. The portfolio offers different connector configurations to meet requirements including automotive environments, design flexibility, compact module design and automated assembly.
CF1 and CF2 are designed for automotive applications requiring vibration resistance and operation at temperatures up to 125°C, while their direct Board-to-FPC connection eliminates the need for relay wiring harnesses. CF3 adds a vertical mating configuration and SMD design, supporting flexible wiring layouts, module downsizing and automated assembly.
Specifications
| Type | No. of pins | Rated current | Rated voltage | Heat resistance | Datasheet | CAD data |
|---|---|---|---|---|---|---|
| CF1 | 4,6,8,10 | 2.0A per pin contact | 50V DC | 125°C | Download | Download |
| CF2 | 20,28,32,40 | 1.0A per pin contact | 50V DC | 125°C | Download | Download |
| CF3 | 28 | 1.0A per pin contact | 50V DC | 125°C | Download | Download |
Key features
- High reliability in demanding environments
- Heat resistance up to 125°C
- Secure and reliable mating
- Stable double-sided contact design
- Direct Board-to-FPC connectivity
- Space- and weight-saving design
- Reduced assembly and process complexity
- Flexible integration for compact electronic designs
