NCR-18500A
-Cylindrical Type-
Product specifications for this product
| Item | Product specifications |
|---|---|
| Type | High Capacity Models (Ni System) |
| Diameter (max.) (with tube) | 18.5 mm |
| Height (max.) (with tube) | 49.5 mm |
| Height (max.) (without tube) | - |
| Weight (max. approx.) | 34.5 g |
| Note | - |
| Nominal capacity (min.) | 1940 mAh |
| Nominal capacity (typ.) | 2040 mAh |
| Nominal voltage | 3.6 V |
Downloads
ISO & TS certificate
| Name | Size | Date | Language |
|---|---|---|---|
| ISO 9001 Certificate of Wuxi factory | 167.1 KB | 08.04.2020 | English |
| ISO 14001 Certificate of Wuxi factory | 202.8 KB | 08.04.2020 | English |
Safety information
| Name | Size | Date | Language |
|---|---|---|---|
| Product Safety Data Sheet Li-ion rechargeable | 230.8 KB | 09.02.2021 | English |
Other
| Name | Size | Date | Language |
|---|---|---|---|
| Short-Form-Catalog | 8.1 MB | 07.03.2025 | English |
